 Output Power

 13hp @ 8500 omw/min

 Propeller

 27x12, 29x9

 Weight

 2500g/3040g (excl./incl. muffler and ignition)

  Delivery includes: spark plugs, ignition and mufflers.



Technical  Specification:
 Displacement                         (Cylinder Inhoud)  130                      ccm

 Output Power                                (Vermogen)

 13   hp
   kW
 Thrust                                            (Trekkracht)  28.5  kg
 Speed Range                                   (Toerental)  1300 - 8500  rpm (omw/min)
 Propeller  27x12 - 29x9  inch
 Ignition power supply      (Spanning ontsteking)  4.8 - 12  Volt
 Spinner/Prop bolt thread            (schroefdraad)    mm
 Gas/Oil mix ratio            (Brandstof verhouding)  30 : 1  gas : oil
 Weight:
 Engine  2500  gram
 Muffler  350  gram
 Ignition  190  gram
 Documentation:
 User Manual               (Gebruikers Handleiding)

 DLE130 User Manual

 Afstellen Ontsteking  Zie item: Afstellen ontsteking
 Link naar Fabrikant  DLEngine
 Links:
 DLE130 Spare Parts  DLE130 Spare Parts t.b.d.
 Comparable Brushless Engine

Delivery overview of the DLE130:

DLE130 Delivery overview
