DLA128 128cc 4-cyl rc model gas engine (13hp, 4000gr)

DLA128

 Output Power

 13hp/9.7kW

 Propeller

 27x10; 28x10; 29x10

 Weight

 3400g/4000g (excl./incl. muffler and ignition)

  Delivery includes: spark plugs (4), ignitions (2) and mufflers (2).

 << Back

 Technische Specificatie:
 Cylinder Inhoud  128   ccm
 Vermogen   13   hp
 9,7  kW
 Trekkracht  28kg  kg
 Toerental  1400 - 8000  omw/min
 Propeller  27x10.. 29x10   inch
 Spanning elektronische ontsteking  7.2 - 8.4   Volt
 Prop-shaft / spinner-bolt  10mm / M5
 Brandstof verhouding  40 : 1  benzine : olie
 Gewicht:
 Motor  3400 gram
 Uitlaat  120 gram
 Ontsteking  180  gram
 Documentatie:
 Gebruikers Handleiding
 Link naar Fabrikant  DLAengine
 Links:
 DLE128 Onderdelen  t.b.d.
 Vergelijkbare Elektro Motor  -



The DLA128 Quad gas engine from DLA is especially developped for scale models which need a nice gas engine. Large models which need an inline can use this engine.



Usefull facts and figures:

The CDI can be used using a standard 2S LiPo.

The exhaust flens size is equal to e.g. a DLE30.

Carburetor: Walbro WJ-805



Detailed pictures of the DLA Gas Engine DLA128 Quad for rc model and scale airplanes:















!
