 Output Power

 5.2hp/3.8kW

 Propeller

 22x8, 22x10, 23x8

 Weight

 1350g/1550g (excl./incl. muffler and ignition)

  Delivery includes: spark plug, ignition and muffler.



Technical  Specification:
 Displacement                         (Cylinder Inhoud)  55                                 ccm

 Output Power                                (Vermogen)

 5.2   hp
 3.8   kW
 Thrust                                            (Trekkracht)    kg
 Speed Range                                   (Toerental)  1500 - 7800  rpm (omw/min)
 Propeller  22x8, 22x10, 23x8  inch
 Ignition power supply      (Spanning ontsteking)  4.8 - 6  Volt
 Spinner bout schroefdraad  M5 - 5mm  mm
 Gas/Oil mix ratio            (Brandstof verhouding)  30 : 1  gas : oil
 Weight:
 Engine  1350  gram
 Muffler  100  gram
 Ignition  100  gram
 Documentation:
 User Manual               (Gebruikers Handleiding)  RCGF55 User Manual
 Afstellen Ontsteking  Zie item: Afstellen ontsteking
 Link naar Fabrikant  RCGF
 Links:
 RCGF-55 Spare Parts  RCGF55 Spare Parts
 Comparable Brushless Engine  -

The engine requires a fuel/oil mix between 25:1 and 40:1 (recommended : 30:1). Use two stroke engine oil.



Engine dimensions:

Engine-flange dimensions:

Exploded view:



Important Notice: You must read the warranty and operating instructions that are provided with the engine. Any modification of or disassembly of the engine while under warranty will VOID the warranty. If you have an engine that does not run properly please contact us. DO NOT take the engine apart as this will VOID the Warranty. Crash damage is NOT covered under warranty. The warranty is from RCGF engines and NOT BigPlanes. We are a Dutch distributor for RCGF. This warranty applies only to RCGF products purchased from BigPlanes. If you have to return the engine, please retain a copy of its serial number.
