Voltage regulators UBEC

!

WIKE RC High Power UBEC: 15A, dual input and output with fail safe switch

WIKE R/C
WIKERC_DL517

The 15A voltage regulator is a switch-mode DC-DC regulator. This regulator is very suitable for big fixed-wing aircrafts because it can supply a huge current and it contains dual input and output terminals for improved reliability.

Input Voltage:    upto 16V
Output Voltage:  4.7 - appr. batt. voltage (adjustable)
Output Current:  15A continuous
Input and output connectors are of type JR.

IBEF Ignition Battery Eliminating Filter, WIKE R/C, Down and Locked

WIKE R/C
WIKERC_IBEF21

This device from WIKE R/C Products will allow you to safe the weight of an extra ignition battery and provides an integrated engine kill switch.The IBEF is designed to be plugged into the receiver and run the ignition from the receiver batteries or power system. Ignition power can be turned on and off by assigning the channel the IBEF is plugged into to a 2 position switch. A spare receiver channel is needed to use this switch.  A remote mountable led is included to indicate ignition arming status.

UBEC 8A, 2-3 cells LiPo, selectable output voltage 5/6V

Hobbywing
HWUBEC8

The 8A-UBEC is a switch-mode DC-DC regulator capable to deliver 8 - 15A.

Input Voltage:     6 - 12V  (2 - 3 cells LiPo)
Output Voltage:  5 or 6V (manual selectable)
Output Current:  8A continuous, 15A maximum

This UBEC is very suitable for big fixed-wing aircrafts because it can supply a big current and it contains 2 output terminals towards the receiver for improved reliability. It also contains a battery capacity indicator (4 leds) and an on/off switch.

UBEC 3A, 2-6 cells LiPo, selectable output voltage 5/6V

Hobbywing
HWUBEC3

The 3A-UBEC is a switch-mode DC-DC regulator. This UBEC can be used to supply the power for the electronic ignition system of a gas engine or the receiver and servos.

The 3A-UBEC is a switch-mode DC-DC regulator. This UBEC can be used to supply the power for the electronic ignition system of a gas engine or the receiver and servos.

Input Voltage:    6 - 26V  (2 - 6 cells LiPo)
Output Voltage:  5 or 6V (manual selectable)
Output Current:  3A continuous
